CAD PDW-700HH | Dual UHF Handheld Wireless System | 902–925MHz with Auto Frequency Selection

CAD Audio AMS-PDW-700HH  (CAD PDW700 HH)

Dual Wireless Handheld Microphone System

CAD PDW-700HH is a dual-channel UHF wireless microphone system designed for performers, presenters, DJs, and venues needing reliable, interference-free operation. Featuring two handheld transmitters and a rugged receiver, it offers natural sound, excellent feedback rejection, and minimal handling noise—making it perfect for stage and studio alike.

CAD PDW-700HH Competitive Differences

• Operates in 902–925MHz UHF band to avoid TV and FCC interference
• Auto frequency agility with infrared pairing for quick setup

CAD PDW-700HH Description

The CAD PDW-700HH is part of the PROformance series, developed with input from top audio professionals to deliver outstanding performance at a fraction of the price of competing systems. Each handheld mic uses a unidirectional Neodymium dynamic capsule that captures clean, natural audio with excellent rejection of feedback and ambient noise. The receiver features two independent frequency-agile channels, allowing multiple systems to be used simultaneously without interference. Infrared syncing makes pairing easy, and onboard controls include mute switches and battery level indicators for each mic. Built for demanding environments, the PDW-700HH offers up to 200 feet of operating range and a high-resolution 24-bit/48kHz digital audio path with a low 3ms latency. Balanced XLR and unbalanced 1/4" outputs make it easy to integrate into any sound system. This system is a great fit for schools, churches, event venues, and touring performers who need consistent wireless performance without breaking the bank. Backed by a 5-year warranty, the PDW-700HH offers unbeatable value and reliability.

Model Features

• Dual handheld UHF transmitters with dynamic cardioid capsules
• Receiver with two independent frequency-agile channels
• Infrared sync for easy pairing
• Digital audio with 24-bit/48kHz sampling and 3ms latency
• Balanced XLR and unbalanced 1/4" outputs
• Operating range up to 200 feet
• 5-year manufacturer warranty

Model Specifications

• Max Operating Range: Up to 200 ft
• Frequency Range: 902–925MHz UHF
• Audio Frequency Response: 50Hz – 20kHz
• Modulation: DQPSK
• Receiver Sensitivity: < -90dBm
• Dynamic Range: >90dB(A)
• Digital Sampling: 24-bit / 48kHz
• Latency: 3ms
• Outputs: XLR balanced, 1/4" unbalanced mix out
• Dimensions (Receiver): 7.88 x 4.94 x 1.75 in
• Weight: 0.75 lb
• UPC: 631922109863

What's In The Box

• Dual handheld wireless microphones
• Dual-channel wireless receiver
• AC power adapter
• Quick start guide
