FBT VHA 118.2 SA | 18in - 143dB | 2500W Active Subwoofer

FBT VHA 118.2 SA  (FBT VHA-118.2-SA)

Powered PA Subwoofer

FBT VHA 118.2 SA is a high-performance active bass-reflex subwoofer designed to provide extended low-frequency support for professional sound reinforcement systems. Engineered to complement the Horizon series line array systems, it delivers powerful and controlled bass output for touring productions, large-scale events, and permanent installations.

FBT VHA 118.2 SA Competitive Differences

• 2500W RMS Class-D amplifier with integrated DSP processing
• High-excursion 18" woofer delivering low-frequency response down to 30Hz

FBT VHA 118.2 SA Description

The FBT VHA 118.2 SA is designed to deliver deep and controlled low-end performance in demanding professional audio environments. At the heart of the system is a high-excursion 18-inch woofer equipped with a 4-inch voice coil, providing accurate and powerful bass reproduction for live sound reinforcement.

A built-in 2500W RMS Class-D amplifier powers the subwoofer while advanced DSP processing provides system optimization and protection. Six selectable presets allow users to quickly configure the subwoofer for different system setups, including cardioid configurations that help control low-frequency dispersion and reduce stage bleed.

The cabinet is constructed from rugged 18mm Baltic birch plywood and finished with a durable scratch-resistant coating designed to withstand the demands of touring and rental environments. A powder-coated steel grille with internal acoustic fabric protects the transducer while maintaining acoustic transparency.

The rear control panel offers simple system integration with gain adjustment, preset selection, and XLR input and output connectors for clean signal routing. With high output capability and extended low-frequency response, the VHA 118.2 SA provides the powerful foundation required for modern professional sound systems.

VHA 118.2 SA Features

• Active bass-reflex subwoofer design
• 18-inch high-excursion woofer with 4-inch voice coil
• 2500W RMS Class-D amplifier
• 5000W peak amplifier power
• Integrated DSP with six selectable presets
• Cardioid configuration capability
• Rugged 18mm Baltic birch plywood cabinet
• Scratch-resistant black finish
• Powder-coated steel grille with acoustic fabric
• XLR input and output connections

VHA 118.2 SA Specifications

• Configuration: Active Bass Reflex
• Low Frequency Driver: 18 in woofer, 4 in voice coil
• Amplifier Power: 2500W RMS
• Peak Power: 5000W
• Frequency Response: 30 Hz (preset dependent)
• Maximum SPL: 137 dB continuous / 143 dB peak
• Dispersion: Omnidirectional
• Input Impedance: 22 kΩ
• Input Connector: XLR IN / OUT
• Power Requirements: 650 W
• Cabinet Material: Baltic birch plywood
• Dimensions: 24 x 28 x 28.3 in (611 x 711 x 720 mm)
• Weight: 134 lb (60.8 kg)

What's In The Box

• FBT VHA 118.2 SA Subwoofer
• Power Cable (5 m / 16.4 ft)
