RF Venue D-OMNID5 | 5-Channel Wireless Mic Upgrade Pack | 360° Diversity Omni Antenna Coverage

RF VENUE D-OMNID5  (RF Venue DOMNID5)

Wireless Microphone Antenna Distribution Bundle

The RF Venue D-OMNID5 is a complete 5-channel wireless microphone upgrade pack combining antenna distribution, polarization-diversity reception, RF cabling, and DC power distribution in one coordinated system. The Diversity Omni Antenna provides 360-degree coverage while the DISTRO5 HDR distributes one diversity antenna pair to as many as five wireless microphone receivers from a compact half-rack enclosure.

RF Venue D-OMNID5 Competitive Differences

• Turnkey RF distribution bundle supports up to 5 diversity wireless microphone receivers
• Diversity Omni Antenna combines vertical and horizontal antenna elements in one compact assembly
• 360-degree omnidirectional coverage is ideal for centrally positioned antennas, multi-zone spaces, and outdoor applications
• Polarization-diversity design helps maintain reception as wireless microphone orientation changes
• DISTRO5 HDR provides high-dynamic-range RF distribution across the 470–698 MHz range
• Half-rack DISTRO5 HDR can be cascaded with another unit to distribute RF to as many as 9 diversity receivers in 1RU
• Included 25-foot antenna cables and 1.5-foot BNC interconnect cables provide the RF connections required for the system
• 12V DC power output supplies up to 5A for compatible wireless receivers and other 12V rack equipment

RF Venue D-OMNID5 Description

The RF Venue D-OMNID5 is designed for wireless microphone systems that need broad RF coverage without relying on two separately positioned omnidirectional antennas. Its Diversity Omni Antenna incorporates two antenna elements on a single stand, capturing vertically and horizontally polarized RF signals and providing separate A and B diversity outputs.

The antenna provides a 360-degree azimuth pattern, making it particularly useful when performers, presenters, or wireless microphones move around the antenna rather than remaining in one direction. RF Venue recommends the Diversity Omni for smaller spaces, multi-zone installations, and outdoor environments where wide-area coverage is needed. Typical coverage can extend to approximately 100 feet from the center under suitable RF conditions, although actual range depends on the surrounding environment and system configuration.

The DISTRO5 HDR provides the RF distribution platform for the bundle. Its High Dynamic Range circuitry is designed to maintain linearity across a wide range of RF signal levels while distributing one diversity antenna pair to five diversity output pairs. The compact half-rack chassis also includes rack-mount hardware, and two DISTRO5 HDR units can be cascaded to serve up to nine diversity receivers in a single 1RU rack space.

Power distribution is integrated into the system as well. The DISTRO5 HDR provides a 12V DC output rated for up to 5A for compatible rack equipment and also includes a 12V DC input for applications requiring external DC or battery operation. Two 25-foot RF Venue Low Loss Antenna Cables, ten 1.5-foot Low Loss BNC Interconnect Cables, and a DC-OCTOPUS-CABLE complete the bundle for a clean, organized wireless microphone installation.

D-OMNID5 Features

• Complete RF antenna and power distribution package for up to 5 wireless microphone channels
• Includes DISTRO5 HDR antenna distribution system
• Includes Diversity Omni polarization-diversity omnidirectional antenna
• 360-degree azimuth antenna coverage
• Vertical monopole and horizontal folded-loop antenna elements
• Separate A and B diversity antenna connections
• Helps maintain RF reception regardless of changing wireless microphone orientation
• Ideal for centrally positioned antennas, multi-zone systems, and wide-area outdoor applications
• Typical Diversity Omni coverage range up to approximately 100 ft from center, depending on local conditions
• Compact antenna design supports stand mounting
• Weather-resistant antenna cover included
• DISTRO5 HDR distributes 1 diversity input pair to 5 diversity output pairs
• DISTRO5 HDR operates across 470–698 MHz
• High Dynamic Range RF architecture
• Compact half-rack DISTRO5 HDR chassis
• Two DISTRO5 HDR units can be cascaded for up to 9 diversity receivers in 1RU
• 12V DC output provides up to 5A for compatible equipment
• 12V DC input supports externally powered and battery-operated applications
• Includes low-loss antenna and BNC interconnect cabling

D-OMNID5 Specifications

• Bundle Type: 5-channel wireless microphone antenna and power distribution upgrade pack
• Wireless Microphone Capacity: Up to 5 diversity receiver channels
• DISTRO5 HDR Frequency Range: 470–698 MHz
• DISTRO5 HDR RF Inputs: 1 diversity pair, BNC
• DISTRO5 HDR RF Outputs: 5 diversity pairs, BNC
• DISTRO5 HDR RF Impedance: 50 ohms
• DISTRO5 HDR Power Supply: Internal, 100–240 VAC, 50/60 Hz, 2A
• DISTRO5 HDR DC Input: 12V DC, 250mA
• DISTRO5 HDR DC Output: 12V DC, 5A
• DISTRO5 HDR DC Output Connector: Anderson Powerpole
• DISTRO5 HDR Dimensions: 8.80 x 8.25 x 1.75 in (223.5 x 210 x 44.5 mm)
• DISTRO5 HDR Weight: 3.7 lb (1.7 kg)
• Diversity Omni Operating Frequency: 470–616 MHz, with usable range to 470–698 MHz where permitted
• Diversity Omni Bandwidth: 146 MHz
• Diversity Omni Impedance: 50 ohms
• Diversity Omni Coverage Pattern: 360-degree azimuth
• Vertical Element Gain: +2 dBd at 500 MHz
• Horizontal Element Gain: -2 dBd at 500 MHz
• Diversity Omni Connectors: (2) BNC female
• Mount Threads: 1/4-20, 3/8-16, and 5/8-27
• Antenna Length: 4.13 in (105 mm)
• Antenna Height: 8.03 in (204 mm)
• Antenna Weight: 0.41 lb (187 g)
• Antenna Operating Temperature: -9 to 130 degrees F (-23 to 54 degrees C)
• Antenna Color: Black and Gold

What's In The Box

• (1) DISTRO5 HDR
• (1) IEC Power Cord
• (1) Set of Short and Long Rack Ears
• (1) Half-Rack Connecting Plate and Mounting Hardware
• (1) Diversity Omni Antenna
• (1) Diversity Omni Stand Mount
• (1) Diversity Omni Weather-Resistant Cover
• (2) 25 ft RF Venue Low Loss Antenna Cables
• (1) 10-Pack of 1.5 ft RF Venue Low Loss BNC Interconnect Cables
• (1) DC-OCTOPUS-CABLE
